Mazda BT50 Sahara Bumper

Mazda BT50 Sahara Bumper

DESIGN & DEVELOPMENT:
Based on the successful Deluxe Bar design, the Sahara bumper for the Mazda BT-50 incorporates the same improved cooling features to aid airflow to the powerful turbo inter-cooled engines. Likewise, to integrate traditional ARB bar styling to the Mazda, the O.E bumper and inner guards are cut and trimmed leaving bumper in fill between the headlights and bar top pan as well as removing excess inner guard material so as to match the under wing panel angle. As with other Sahara bumpers, tube kits and buffers must be ordered separately. Please refer to the table on page 2 for part numbers.

PROTECTION & STYLING CHARACTERISTICS:
• Durable steel construction for maximum protection
• Incorporates ARB’s renowned multi fold upswept and tapered wing design for optimum strength and approach angle
• Split pan design for maximum strength and airflow • Extensive under bar protection panels on centre and either side
• Vehicle specific design to complement the BT50 and maximise functionality

PROTECTION & STYLING CHARACTERISTICS:
• Superbly engineered, air bag compatible mounting system secures to chassis via high tensile bolts
• Equally suited to winch and non-winch applications
• Will accommodate Warn, Magnum, Smittybilt & Bushranger low mount model electric winches.
• Twin Hi-Lift jacking points located in the pan of the bar
• Provision to accommodate ARB Intensity LED and a range of IPF driving lights
• Provision for ARB Fog Lights
• Recessed indicators and parking lights
• Durable urethane buffers
• Retains original equipment tow points
• Two aerial brackets located on the optional alloy Sahara tube
• Finished in a hard-wearing Millennium Grey powder coat with the added option of colour coding to individual vehicles

COMPLIMENTS:
Part Number Description
5140020 Sahara Tube Kit
5100020 Buffer Kit
5100030 Buffer kit (no tube)

FOG LIGHT:
ARB Fog Light surrounds incorporating recessed clearance/indicator light assemblies are fitted as standard and can be upgraded to include the optional ARB Fog Light kit P/No 6821201. Image at right shows the surround with blank in place. Mazda BT50 2011 on - Sahara Bumper || www.arb.com.au DRIVING LIGHT MOUNTS: Sahara bars include laser cut holes in the top of the centre pan for fitment of a range of compatible driving lights such a ARB Intensity LED & IPF 108, 808, 800 & 900 series lights.

AERIAL MOUNTS:
Two aerial mounts are welded to the centre alloy tube to allow fitment of UHF/AM radio and mobile phone aerials/ antennas.

HILIFT JACKING POINTS:
Each bar comes standard with two reinforced HiLift jacking points fitted to the centre pan. Mazda BT50 2011 on - Sahara Bumper || www.arb.com.au

NUMBER PLATE MOUNT:
To aid airflow through the split pan when a winch is installed, the number plate is fitted to a hinged mount (supplied with optional winch mount kit P/No 3540050) that allows it to be lifted so that the roller fairlead can be accessed during winch operation. When no winch is fitted the number plate is affixed directly to the bar over the roller fairlead slot. WINCH MODEL FITMENT: BT-50 Sahara bumpers fit the following winches:
• Warn M8000
• Warn M9000
• Warn XD9000
• Warn XP9500
• Warn XDC
• Magnum 8K
• Magnum 10K
• Bushranger DV-9TH
• Bushranger DS-9.5TH
• Smittybilt X20 10,000lb

An optional winch mounting kit P/No 3540050 is required for fitting all winch models.
A winch cover panel for the top pan is included with the bar for use when no winch is fitted
