Φορτιστής REDARC BCDC CORE IN-CABIN 25A DC BATTERY CHARGER

Ο Φορτιστής της REDARC είναι ιδανικος για να φορτίσετε την δεύτερη μπαταρία του αυτοκινήτου ή του τρειλερ.

REDARC’s BCDC Core 25A DC to DC In-Cabin Battery Charger is the next evolution of the legendary BCDC platform that has been powering off-grid adventures for over 10 years.

The BCDC Core is the perfect DC-to-DC charging solution for in-cabin, canopy, or battery box setups where dust and weatherproofing aren’t required. Each BCDC Core features REDARC’s tried and tested dual input DC charging tech plus an MPPT solar regulator and Green Power Priority all in the familiar and compact BCDC form factor. These features allow the BCDC Core to efficiently charge from both the alternator and solar simultaneously, ensuring maximum charge capacity no matter the situation.

Looking for a DC-DC Charger for an under-bonnet installation? The REDARC BCDC Classic range in 25amp, 40amp, and 50amp models could be what you’re looking for.

MAX CHARGE EFFICIENCY

The BCDC Core features a Maximum Power Point Tracking (MPPT) solar regulator and ‘Green Power Priority’. With these features the BCDC Core will charge from both solar and the alternator simultaneously, maximizing its charge rate and minimizing the load on your alternator, saving fuel.

COMPACT & SILENT

With no loud fans or relays and a small form factor, the BCDC Core can be tucked away, leaving room in the cabin for more important things. Don’t ruin the look of your interior with bulky electronics. Hide it under the rear floor, behind a side panel, or under the seats, and make your power setup look like it was meant to be there.

LITHIUM READY

With chemistry-specific charging profiles, including lithium the BCDC Core ensures your batteries are ready for your next adventure. The award-winning technology in the BCDC Core has been independently verified and tested to ensure battery life is maximized, charging your battery to a proven 100%.*
For most applications, the BCDC Core 25A is suitable for battery bank sizes of 60-200AH for AGM and lead acid and up to 100AH for lithium. Check the manufacturer’s data for your battery and ensure that the ‘Continuous Current Rating’ of the charger does not exceed the manufacturer’s recommended maximum charging current. For higher capacity needs of over 200AH, REDARC recommends the BCDC Core 40A.

*Large-capacity battery banks may require a few cycles to fully charge.

BACKED BY THE BEST

The BCDC Core is designed, tested, and manufactured in Australia and is backed by our leading technical support and national REDNetwork-certified installer network.

If you’re heading out into the bush and want to get there and back again safely – you can trust REDARC.

FEATURES

• Suitable for in-cabin and canopy installations only
• Compact form factor
• Simultaneous DC and solar charging with Green Power Priority
• Maximizes the performance and life of your auxiliary battery
• Suits 12V/24V standard and variable voltage/smart alternators
• Suitable for AGM, GEL, standard lead acid, calcium and Lithium (LiFePO4) batteries
• Suitable for use on vehicles with conventional alternator charging systems

SPECIFICATIONS

GTIN_BARCODE	9338628007035
BRAND	REDARC
BATTERY CHEMISTRY	Standard Lead Acid, Calcium content, Gel, AGM or LiFePO4 type only
CONTINUOUS RATING	25A
POWER TYPE – AC DC	DC TO DC
NO LOAD CURRENT	<100mA
SOLAR INPUT VOLTAGE	9 – 32V
SOLAR SWITCH ON VOLTAGE	9V
STANDBY CURRENT	<8mA
OPERATING TEMPERATURE	-10°C to 80°C
WEIGHT	35.3 oz (1 kg)
HEIGHT	1.5″ (37 mm)
WIDTH	4.7″ (120 mm)
DEPTH | LENGTH	6.5″ (165 mm)
WARRANTY	2 Years
CONNECTOR TYPE	Bare wire
INPUT VOLTAGE	9 – 32V
OUTPUT VOLTAGE	12V DC
MAX. CHARGING VOLTAGE	15.3V
MAX. RATED OUTPUT CURRENT	25A
NOMINAL OUTPUT POWER	375W
INPUT FUSE RATING	40A (Not supplied) REDARC FK40 recommended
OUTPUT FUSE RATING	60A (Not supplied) REDARC FK60 recommended

MANUAL

• BCDC Core Instruction Manual EN
• BCDC Core Install Manual EN FR DE IT ES PL AR
• BCDC Brochure EN
